| Product name |
Features |
Specifications/Approvals |
Continuous operating temperature |
Sizes |
Shrink ratio |
| SUMITUBE™ A |
Heat-shrinkable tubing / Single / Non Flame Retarded |
- |
-55 to 105℃ |
1.5～25mm |
Approx. 40% |
| |
[General purpose heat-shrinkable tubing] |
| SUMITUBE™ LA |
Heat-shrinkable tubing / Single / Non Flame Retarded |
UL / CSA / PSE / SAE |
-55 to 105℃ |
30～150mm |
Approx. 35% |
| |
[Large diameter heat-shrinkable tubing] |
| SUMITUBE™ A4 |
Heat-shrinkable tubing / Single / Non Flame Retarded |
- |
-55 to 105℃ |
3/64～2inch |
min. 50% |
| |
[Weather resistant heat-shrinkable tubing] |
| SUMITUBE™ C |
Heat-shrinkable tubing / Single / Non Flame Retarded |
- |
-55 to 105℃ |
1～25mm |
Approx. 40% |
| |
[General purpose heat-shrinkable tubing (shrinks at low temperature)] |
| SUMITUBE™ C (UL) |
Heat-shrinkable tubing / Single / Non Flame Retarded |
UL |
-55 to 105℃ |
3.2～7mm |
Approx. 40% |
| |
[105℃ rating, heat-shrinkable tubing (shrinks at low temperature)] UL recognized |
| SUMITUBE™ D |
Heat-shrinkable tubing / Single / Non Flame Retarded |
- |
-55 to 135℃ |
3/64～1/2inch |
min. 50% |
| |
[Semi-rigid heat-shrinkable tubing] |
| SUMITUBE™ A2 |
Heat-shrinkable tubing / Single / Non Flame Retarded |
SAE |
-55 to 135℃ |
64/3～4inch |
min. 50% |
| |
[Clear flexible heat-shrinkable tubing] SAE-AS-23053 |
| SUMITUBE™ B |
Heat-shrinkable tubing / Single / Flame Retarded |
- |
-45 to 120℃ |
2～25mm |
Approx. 40% |
| |
[General purpose flame-retarded heat-shrinkable tubing] |
| SUMITUBE™ LB |
Heat-shrinkable tubing / Single / Flame Retarded |
- |
-45 to 120℃ |
30～150mm |
Approx. 35% |
| |
[Large diameter flame-retarded heat-shrinkable tubing] |
| SUMITUBE™ F (Z) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / PSE |
-55 to 105℃ |
1～50mm |
min. 50% |
| |
[105℃ rating, flame-retarded heat-shrinkable tubing] UL recognized |
| SUMITUBE™ F3 (Z) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / PSE |
-55 to 105℃ |
1～10mm |
min. 50% |
| |
[Thin wall, very flexible flame-retarded heat-shrinkable tubing] UL recognized |
| SUMITUBE™ NHR2 |
Heat-shrinkable tubing / Single / Flame Retarded |
UL |
-55 to 125℃ |
1～30mm |
min. 50% |
| |
[125℃ rating, halogen-free, flame-retarded, heatresistant tubing] UL/cULus recognized |
| SUMITUBE™ NHR4 |
Heat-shrinkable tubing / Single / Flame Retarded |
UL |
-55 to 125℃ |
1～10mm |
min. 50% |
| |
[125℃ rating, halogen-free, thin wall, very flexible, flame-retarded, heat-resistant tubing] UL recognized |
| SUMITUBE™ R |
Heat-shrinkable tubing / Single / Flame Retarded |
SAE |
-70 to 120℃ |
1/8～2inch |
min. 50% |
| |
[Rubber-like, flame-retarded heat-shrinkable tubing] SAE |
| SUMITUBE™ V (300V) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / PSE |
-30 to 105℃ |
3/64～1inch, 1.5～25mm |
min. 50% |
| |
[Clear, flame-retarded heat-shrinkable tubing] |
| SUMITUBE™ F2 (Z) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA / PSE |
-55 to 125℃ |
1～50mm |
min. 50% |
| |
[125℃ rating, flame-retarded heat-shrinkable tubing] UL/CSA recognized |
| SUMITUBE™ F4 (Z) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA / PSE |
-55 to 125℃ |
1～10mm, 1/2～1inch |
min. 50% |
| |
[125℃ rating, flame-retarded heat-shrinkable tubing] UL/CSA recognized |
| SUMITUBE™ B2 |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA / SAE |
-55 to 135℃ |
3/64～4inch |
min. 50% |
| |
[Flexible flame-retarded heat-shrinkable tubing] SAE-AMS/UL/CSA recognized |
| SUMITUBE™ B2 (3X) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA |
-55 to 135℃ |
1.5/0.5～40/13mm |
min. 66% |
| |
[High shrink ratio flame-retarded heat-shrinkable tubing] UL/CSA recognized |
| SUMITUBE™ B8 |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA / PSE |
-55 to 125℃ |
3/64～1inch |
min. 50% |
| |
[125℃ rating, semi-rigid flame-retarded heatshrinkable tubing] UL/CSA recognized |
| SUMITUBE™ V (600V) |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / PSE |
-30 to 105℃ |
3/64～1inch |
min. 50% |
| |
[105℃ rating, transparent flame-retarded heatshrinkable tubing] UL/CSA recognized |
| SUMITUBE™ K |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / CSA / PSE / SAE |
-55 to 175℃ |
3/64～1inch |
min. 50% |
| |
[Highly heat/oil/chemical resistant, clear, flame-retarded heat-shrinkable tubing] SAE/UL/CSA recognized |
| SUMITUBE™ K2 |
Heat-shrinkable tubing / Single / Flame Retarded |
UL / PSE / SAE |
-55 to 175℃ |
3/64～1inch |
min. 50% |
| |
[Highly heat/oil/chemical resistant, clear, flame-retarded heat-shrinkable tubing] SAE/UL recognized |
| SUMITUBE™ AN25 |
Heat-shrinkable tubing / Single / Flame Retarded |
SAE |
-75 to 150℃ |
1/8～2inch |
min. 50% |
| |
[Highly heat/oil/chemical resistant, flame-retarded heatshrinkable tubing] VG/SAE recognized |
| SUMITUBE™ B6 |
Heat-shrinkable tubing / Single / Flame Retarded |
- |
-55 to 135℃ |
1/8～1/2inch |
min. 50% |
| |
[Semi-rigid flame-retarded heat-shrinkable tubing] |
| SUMITUBE™ O2C |
Heat-shrinkable tubing / Dual / Non Flame Retarded |
- |
-55 to 105℃ |
2～10mm, 1/8～1inch |
min. 50% |
| |
[Dual wall heat-shrinkable tubing with meltable adhesive for fixing and waterproofing of straight-shaped objects] |
| SUMITUBE™ W3C |
Heat-shrinkable tubing / Dual / Non Flame Retarded |
- |
-55 to 105℃ |
1/8～1inch |
min. 60% |
| |
[Dual wall heat-shrinkable tubing with meltable adhesive for waterproofing of irregular-shaped objects] |
| SUMITUBE™ O2B2 |
Heat-shrinkable tubing / Dual / Flame Retarded |
UL / CSA / SAE |
-55 to 125℃ |
1/4～1-1/2inch |
min. 50% |
| |
[Dual wall heat-shrinkable tubing with meltable adhesive for fixing and waterproofing of straight-shaped objects] SAE/UL/CSA recognized |
| SUMITUBE™ W3F2 |
Heat-shrinkable tubing / Dual / Flame Retarded |
UL / CSA |
-55 to 125℃ |
1/8～1inch |
min. 60% |
| |
[Dual wall, flame-retarded heat-shrinkable tubing with meltable adhesive for waterproofing of irregular-shaped objects] UL/CSA recognized |
| SUMITUBE™ W3B2 |
Heat-shrinkable tubing / Dual / Flame Retarded |
UL / CSA / SAE |
-55 to 125℃ |
3/1～40/13mm |
min. 60% |
| |
[Dual wall, flame-retarded heat-shrinkable tubing with meltable adhesive for waterproofing of irregular-shaped objects] SAE-AMS/UL/CSA recognized |
| SUMITUBE™ W3B2 (4X) |
Heat-shrinkable tubing / Dual / Flame Retarded |
UL / SAE |
-55 to 125℃ |
4/1～24/6mm |
min. 75% |
| |
[Dual wall, flame-retarded heat-shrinkable tubing with meltable adhesive for waterproofing of irregular-shaped objects] UL recognized |
| SUMITUBE™ SA2 |
Heat-shrinkable tubing / Dual / Flame Retarded |
- |
-40 to 130℃ |
5.8/1.2～17.8/4.4mm |
min. 75% |
| |
[Dual wall, highly water/heat resistant, high shrink ratio flame-retarded heat-shrinkable tubing with meltable adhesive] |
| SUMITUBE™ SA3 |
Heat-shrinkable tubing / Dual / Flame Retarded |
- |
-40 to 130℃ |
5.8/1.2～17.8/4.4mm |
min. 75% |
| |
[Dual wall, flame-retarded heat-shrinkable tubing with meltable adhesive for harness joints of motor vehicles] |
| SUMITUBE™ W |
Heat-shrinkable tubing / Dual / Non Flame Retarded |
- |
-55 to 105℃ |
1.5～14mm |
min. 60% |
| |
[Dual wall heat-shrinkable tubing with meltable liner] |
